Facilities

Major Manufacturing Facilities

  • Pattern Shop
  • Captive Foundry for Machine tool & metrology quality Castings up to 15 tones single piece.
  • JASH make Plano-Milling Machine size 7000 x 3200 x 1100mm
  • WMW Heckert make Planing Machine Size 3000 x 2200 x 1100 mm.
  • BUTLER, UK make Planer-cum-Plano Milling machine size 3000 x 1000 x 900 mm.
  • BUTLER, UK make Planer-cum-Plano Milling machine size 8000 x 2700 x 1200 mm.
  • Waldrich Coburg, Germany make Planer-cum-Plano Milling machine size 5000 x 1500 x 1100 mm.
  • Gidding & Lewis, USA make Horizontal Boring & Milling Machine size 1660 x 880 x 1200 mm.
  • Mazak, Japan make Horizontal Machining Centre, model H25, size 1500 x 1070 x 1050 mm, Twin Pallets size 800 x 800 mm each with 80 tool ATC.
  • HURON, FRANCE make Bed Type Milling Machine.
  • SKODA, Czech make Floor Type Horizontal Boring & Milling Machine, Model WD160, size 10,500 x 3100 with Rotary Table.
  • Devlieg, USA make CNC Jig Mill Machine with CNC Rotary Table 1000 x 1000 mm and 48 tool ATC.
  • HMT Praga make Universal Milling Machine with 3 axis DRO size 1000 x 250 mm.
  • Horizontal Milling Machine size 1000 x 300 mm.
  • Shaper 600 mm.
  • Lathe Machines.
  • Asquith, England make Radial drilling Machines 80mm capacity – 1 No.
  • GSP, France make Radial drilling Machines 80mm capacity – 1 No.
  • Bonal, USA make Sub-harmonic Vibratory Stress Relieving Equipment.
  • Micro hole drilling machine – 25000 r.p.m. min 0.1mm dia.
  • Well equipped Fabrication setup with Welding Transformers 300 A, 2 Nos.,Gas Welding & Cutting Plant, Layout & Marking Tables
  • Caterpillar make 320KVA DG Set.
  • Various Cranes & Hoist for Material Handling upto 25T.

Measuring & Inspection Facilities


  • Renishaw Laser Interferometer ML-10 / EC10 with full set of optics for measurement of Linear accuracy, straightness, squareness, velocity, Angularity, Flatness, Resolution upto 0.000001 mm. complete with automatic environmental compensation unit EC-10 with material temperature sensors and air sensors. Traceable to NPL, U.K.
  • CNC Three Co-ordinate measuring machine size 1200 x 800 x 600 mm.
  • Rank Taylor Hobson make Automatic Position sensing Photoelectric Auto-collimator with measurement optics for straightness, squareness & flatness resolution 0.01 Arc Seconds with Hewlett-Packard portable computer.
  • Mitutoyo make 600mm Calibrated Step Guage.
  • Rank Taylor Hobson make Precision electronic level Talyvel-1
  • Wyler Switzerland, make Square frame Precision electronic digital level traceable to NPL, New Delhi.
  • Microplan, Italy make Electronic Precision Level.

11- WMW-Niles Make Vertical Turrent Lathe Machine Model DKZ 2500 × 2000 B
